EMCOD MLE200-24DC
Electronic Class P Outdoor Triac Dimmable
Black Powder Coated Steel Enclosure
Black Powder Coated Steel Enclosure
Electrical Parameters
| Input Voltage: | 110-277V 50/60Hz |
| Max. input current: | 1.8A at full load |
| Output voltage without load: | 24.1VDC |
| Output voltage fully loaded: | 24VDC |
| Max. Total Wattage: | 200W |
| Max. Output Current: | 8.3A |
| Efficiency: | 90% |
| Load regulation: | 1% |
| Ripple: | 5% |
H = 10.3, W = 4.06, D = 1.77
