EMCOD MLE96-24DC
Class 2 Electronic Class P Outdoor Triac Dimmable
Black Powder Coated Steel Enclosure
Electrical Parameters
| Input Voltage: |
100-277V 50/60Hz |
| Max. input current: |
1.5A at full load
|
| Output voltage without load: |
24.1VDC |
| Output voltage fully loaded: |
24VDC |
| Max. Total Wattage: |
96W |
| Max. Output Current: |
4A |
| Efficiency: |
90% |
| Load regulation: |
1% |
| Ripple: |
5% |
H = 7.8, W = 3.66, D = 1.61
