EMCOD MLE80-24DC
Class 2 Electronic Class P Outdoor Triac Dimmable
Black Powder Coated Steel Enclosure
Electrical Parameters
| Input Voltage: | 100-277V 50/60Hz |
| Max. input current: | 1.3A at full load |
| Output voltage without load: | 24.1VDC |
| Output voltage fully loaded: | 24VDC |
| Max. Total Wattage: | 80W |
| Max. Output Current: | 3.3A |
| Efficiency: | 90% |
| Load regulation: | 1% |
| Ripple: | 5% |
