EMCOD ML75S12DC Class 2 Magnetic Outdoor Phase cut Dimmable
Black Powder Coated Steel Enclosure
Dimensions H = 8.13, W = 3.93, D = 1.59
Remark
�The unit has additional knockout on the back
Electrical Parameters
| Input Voltage: | 120V 60Hz |
| Max. input current: | 0.75A at full load |
| Output voltage without load: | 13.5VDC |
| Output voltage fully loaded: | 11.5VDC |
| Max. Total Wattage: | 75W |
| Max. Output Current: | 6.2A |
| Efficiency: | 85% |
